This abandoned through truss bridge crosses the Fall River and 1450 Road west of New Albany

New Albany, Wilson County, Kansas

Owner: South Kansas & Oklahoma Railroad

Status: Abandoned

Built 1905

by

King Bridge Company of Cleveland, Ohio

for

St. Louis–San Francisco Railway

Design:
164' Pratt through truss and timber pile trestle

Description:
Pratt through truss bridge over Fall River

Significance:

This unique through truss bridge carries Ball Ford Trail over the Grand River north of Darlington

Darlington, Gentry County, Missouri

Owner: Gentry County

Status: Closed to all Traffic

Built 1907 using a span fabricated 1879

by

Kellogg and Maurice of Athens, Pennsylvania

for

Chicago, Burlington & Quincy Railroad

Design:
175' Pratt through truss and timber pile trestle

Description:
Pratt through truss bridge over Grand River

Significance:

This large quadrangular lattice through truss bridge carries the former Chicago & North Western Railway over Sanitation Road, the Keokuk Junction Railway and the Tazewell & Peoria Railroad in Bartonville

Bartonville, Peoria County, Illinois

Owner: Union Pacific Railroad

Status: In Use

Built 1912

by

King Bridge Company of Cleveland, Ohio and Cleary-White Construction Company of Chicago, Illinois

for

Chicago & North Western Railway

Design:
1-158', 1-137' and 3-118' quadrangular lattice through trusses

Description:
Quadrangular lattice through truss bridge over Sanitation Road, Keokuk Junction Railway and Tazewell & Peoria Railroad

Significance:

This historic deck girder and steel stringer bridge was constructed using a span originally fabricated in 1879

Ralston, Douglas County, Nebraska

Owner: BNSF Railway

Status: In Use

Built 1903 using a secondhand span fabricated 1879

by

Kellogg and Maurice of Athens, Pennsylvania

for

Chicago, Burlington & Quincy Railroad

Design:
25' deck plate girder, 30' steel stringer and concrete slab

Description:
Deck girder and steel stringer bridge over 60th Street

Significance:

This deck plate girder bridge crosses the Big Blue River in Crete and was built with several spans from the original Plattsmouth Bridge

Crete, Saline County, Nebraska

Owner: BNSF Railway

Status: In Use

Built 1901 using spans fabricated 1879 and 1901

by

Kellogg and Maurice of Athens, Pennsylvania and unknown

for

Chicago, Burlington & Quincy Railroad

Design:
2-75' and 7-30' deck plate girders and 20' steel stringer

Description:
Deck plate girder bridge over Big Blue River

Significance:

This Pratt through truss bridge crosses the Big Blue River near the unincorporated community of Hoag

Hoag, Gage County, Nebraska

Owner: BNSF Railway

Status: In Use

Built 1902 at an unknown location

by

King Bridge Company of Cleveland, Ohio

for

Chicago, Burlington & Quincy Railroad

Design:
130' Pratt through truss, timber pile trestle and modular concrete girder

Description:
Pratt through truss bridge over Big Blue River

Significance:

This Baltimore through truss bridge crosses Brush Creek west of Parkville

, Platte County, Missouri

Owner: BNSF Railway

Status: In Use

Built 1905

by

King Bridge Company of Cleveland, Ohio

for

BNSF Railway

Design:
105' Baltimore through truss and concrete modular girder

Description:
Baltimore through truss bridge over Brush Creek

Significance:

This unique through truss and girder bridge was built using numerous different components

Plattsmouth, Cass County, Nebraska to La Platte, Sarpy County, Nebraska

Owner: BNSF Railway

Status: In Use

Built 1903, 1910 and 1924

by

King Bridge Company of Cleveland, Ohio; American Bridge Company of New York and Missouri Valley Bridge & Iron Company of Leavenworth, Kansas

for

Chicago, Burlington & Quincy Railroad

Design:
Pratt and Baltimore through truss, through plate girder and deck plate girder

Description:
Through truss and girder bridge over Platte River

Significance:

This deck plate girder bridge crosses the east channel of the Mississippi River at Quincy

Quincy, Adams County, Illinois

Owner: BNSF Railway

Status: In Use

Built 1960

by

Bethlehem Steel Company of Bethlehem, Pennsylvania and Kansas City Bridge Company of Kansas City, Missouri

for

Chicago, Burlington & Quincy Railroad

Design:
5-105', 2-95' deck plate girders

Description:
Deck plate girder bridge over Quincy Bay

Significance:

This through plate girder bridge carries the former Chicago, Burlington & Quincy Railroad over Rock Creek east of Erie

Erie, Whiteside County, Illinois

Owner: BNSF Railway

Status: In Use

Built 1904

by

King Bridge Company of Cleveland, Ohio

for

Chicago, Burlington & Quincy Railroad

Design:
1-86' and 2-40' through plate girder

Description:
Through plate girder bridge over Rock Creek

Significance:

This steel stringer bridge carries the former Northern Pacific Railway mainline over US Highway 10 in Hawley

Hawley, Clay County, Minnesota

Owner: BNSF Railway

Status: In Use

Built 1959

by

Unknown and Kimmes Construction Company of Hastings, Minnesota

for

Northern Pacific Railway

Design:
1-37', 2-42', 2-46' steel stringers

Description:
Steel stringer bridge over US Highway 10

Significance:

This large polygonal Warren through truss vertical lift bridge carries a partially complete trail across the Missouri River

Boonville, Cooper County, Missouri to New Franklin, Howard County, Missouri

Owner: City of Boonville

Status: Partially Open to Pedestrian Traffic

Built 1932

by

American Bridge Company of New York and Kansas City Bridge Company of Kansas City, Missouri

for

Missouri-Kansas-Texas Railway

Design:
408' polygonal Warren through truss lift bridge

Description:
Polygonal Warren through truss vertical lift bridge over Missouri River

Significance:

This through plate girder bridge carries the former Illinois Central Railroad over Kedzie Avenue north of the Sanitary & Ship Canal

South Lawndale, Chicago, Cook County, Illinois

Owner: Canadian National Railway

Status: In Use

Built 1898

by

Detroit Bridge & Iron Works of Detroit, Michigan; MacArthur Brothers Company of Chicago, Illinois and Winson Brothers Company of Minneapolis, Minnesota

for

Illinois Central Railroad

Design:
80' through plate girder

Description:
Through plate girder bridge over Kedzie Avenue

Significance:

This through plate girder bridge carries the former Chicago, Milwaukee, St. Paul & Pacific Railroad over County Road 69 (former US Highway 69) in Shakopee

Shakopee, Scott County, Minnesota

Owner: Canadian Pacific Kansas City Limited

Status: Open to Traffic

Built 1957

by

Unknown and Kraus-Anderson Construction Company of St. Paul, Minnesota

for

Chicago, Milwaukee, St. Paul & Pacific Railroad

Design:
2-73' through plate girders and 1-45' and 1-50' steel stringer

Description:
Through plate girder bridge over County Road 69 (Business US Highway 169)

Significance:

This Warren through truss bridge carries a spur across the Wood River in East Alton

East Alton, Madison County, Illinois

Owner: Canadian Pacific Kansas City Limited

Status: In Use

Built 1916

by

King Bridge Company of Cleveland, Ohio

for

Cleveland, Cincinnati, Chicago and St. Louis Railway (Big Four)

Design:
125' Warren through truss

Description:
Warren through truss bridge over Wood River

Significance:

This through plate girder bridge carries the former Chicago & North Western Railway over Riverside Avenue in Owatonna

Owatonna, Steele County, Minnesota

Owner: Canadian Pacific Kansas City Limited

Status: Open to Traffic

Built 1901

by

King Bridge Company of Cleveland, Ohio and Widell Company of Mankato, Minnesota

for

Chicago & North Western Railway

Design:
33' through plate girder

Description:
Through plate girder bridge over Riverside Avenue

Significance:

This large Strauss trunnion bascule bridge carries the Union Pacific North Line over the North Branch Chicago River

Logan Square, Chicago, Cook County, Illinois to Lincoln Park, Chicago, Cook County, Illinois

Owner: Union Pacific Railroad

Status: In Use

Built 1916

by

American Bridge Company of New York; Great Lakes Dredge & Dock Company of Chicago, Illinois and Kelly-Atkinson Construction Company of Chicago, Illinois

for

Chicago & North Western Railway

Design:
180' Warren through truss Strauss trunnion bascule span and deck plate girder

Description:
Strauss trunnion bascule bridge over North Branch Chicago River

Significance:

This through plate girder bridge crosses the Tongue River in Cavalier

Cavalier, Pembina County, North Dakota

Owner: Dakota Northern Railroad

Status: In Use

Built 1899 at an unknown location

by

Keystone Bridge Company of Pittsburgh, Pennsylvania

for

Great Northern Railway

Design:
60' through plate girder and trestle

Description:
Through plate girder bridge over Tongue River

Significance:

This large through truss swing bridge carries the former Illinois Central Railroad over the Mississippi River at Dubuque

Dubuque, Dubuque County, Iowa to East Dubuque, Jo Daviess County, Illinois

Owner: Canadian National Railway

Status: In Use

Built 1892 and 1900

by

Keystone Bridge Company of Pittsburgh, Pennsylvania and American Bridge Works of Chicago, Illinois

for

Illinois Central Railroad

Design:
356' Pratt through truss swing span and 2-250', 3-225' Parker through trusses

Description:
Through truss swing bridge over Mississippi River

Significance:

This steel arch bridge is among the most iconic and significant bridges in the United States

St. Louis, St. Louis City, Missouri to East St. Louis, St. Clair County, Illinois

Owner: City of St. Louis

Status: In Use by Automobiles and Light Rail

Built 1867-1874

by

Keystone Bridge Company of Pittsburgh, Pennsylvania and James B. Eads

for

St. Louis and Illinois Bridge Company

Design:
520' and 2-502' ribbed steel deck arch, stone arch and deck girder

Description:
Ribbed steel deck arch bridge over Mississippi River, railroads and city streets

Significance:

This large Parker through truss bridge carries an abandoned railroad across the Marmaton River in Fort Scott

Fort Scott, Bourbon County, Kansas

Owner: City of Fort Scott

Status: Abandoned

Built c. 1910

by

King Bridge Company of Cleveland, Ohio

for

Missouri-Kansas-Texas Railway

Design:
190' Parker through truss and timber trestle

Description:
Parker through truss bridge over Marmaton River

Significance:

This through plate girder bridge carries the former Chicago & North Western Railway over the Norfolk Southern Railway and Industrial Drive near Curran

Curran, Sangamon County, Illinois

Owner: Sangamon County

Status: Abandoned, Awaiting Future Trail Development

Built 1912

by

King Bridge Company of Cleveland, Ohio and Cleary-White Construction Company of Chicago, Illinois

for

Chicago & North Western Railway

Design:
68' through plate girder and 50' deck plate girder

Description:
Through plate girder bridge over Norfolk Southern Railway and Industrial Drive

Significance:

This deck plate girder bridge carries the abandoned Chicago & North Western Railway over Mansion Road northwest of Chatham

Chatham, Sangamon County, Illinois

Owner: Sangamon County

Status: Abandoned, Awaiting Future Trail Development

Built 1912

by

King Bridge Company of Cleveland, Ohio

for

Chicago & North Western Railway

Design:
30' deck plate girder and timber pile trestle

Description:
Deck plate girder bridge over Mansion Road

Significance:

This large through plate girder bridge carries the former Chicago & North Western Railway over Old US Route 54 (former Chicago, Peoria & St. Louis Railroad) near the small town of Curran

Curran, Sangamon County, Illinois

Owner: Sangamon County

Status: Abandoned

Built 1912 and 1923

by

King Bridge Company of Cleveland, Ohio and Unknown

for

Chicago & North Western Railway

Design:
89' through plate girder and 2-13' concrete encased beams

Description:
Through plate girder bridge over Old US Route 54 (former Chicago, Peoria & St. Louis Railroad)

Significance:

This deck plate girder viaduct serves as a wye off the main west approach viaduct to the Highline Bridge

Kansas City, Wyandotte County, Kansas

Owner: Kansas City Terminal Railway

Status: In Use

Built 1918

by

American Bridge Company of New York; D. Munro of Kansas City, Missouri and Kelly-Atkinson Construction Company of Chicago, Illinois

for

Kansas City Terminal Railway

Design:
10 span deck plate girder viaduct

Description:
Deck plate girder viaduct over Berger Avenue

Significance:

This large Pratt through truss and deck girder viaduct serves as the western approach to the Highline Bridge

Kansas City, Wyandotte County, Kansas

Owner: Kansas City Terminal Railway

Status: In Use

Built 1918

by

American Bridge Company of New York; D. Munro of Kansas City, Missouri and Kelly-Atkinson Construction Company of Chicago, Illinois

for

Kansas City Terminal Railway

Design:
Pratt through truss and deck plate girder viaduct

Description:
Pratt through truss and deck girder viaduct over various railroads and streets

Significance:

This large Pratt through truss and deck girder viaduct serves as the western approach to the Highline Bridge

Kansas City, Wyandotte County, Kansas

Owner: Kansas City Terminal Railway

Status: In Use

Built 1918

by

American Bridge Company of New York; D. Munro of Kansas City, Missouri and Kelly-Atkinson Construction Company of Chicago, Illinois

for

Kansas City Terminal Railway

Design:
Pratt through truss and deck plate girder viaduct

Description:
Pratt through truss and deck girder viaduct over various railroads and streets

Significance:

This unique double deck bridge crosses the Kansas River as part of a longer series of viaducts

Kansas City, Wyandotte County, Kansas

Owner: Kansas City Terminal Railway

Status: In Use

Built 1917-1919

by

American Bridge Company of New York; D. Munro of Kansas City, Missouri and Kelly-Atkinson Construction Company of Chicago, Illinois

for

Kansas City Terminal Railway

Design:
2-300' double deck Baltimore through trusses and 132' Warren deck truss

Description:
Double deck Baltimore through truss bridge over Kansas River

Significance:

This large through truss bridge carries the Elgin Branch of the Illinois Prairie Path over the Union Pacific Railroad, Front Street and Wesley Street

Wheaton, DuPage County, Illinois

Owner: DeKalb County Forest Preserve District

Status: Open to Pedestrian Traffic

Built 1901

by

King Bridge Company of Cleveland, Ohio

for

Aurora, Elgin & Chicago Railway

Design:
159' Pratt through truss and prefabricated pedestrian truss spans

Description:
Pratt through truss bridge over Union Pacific Railroad, Front Street and Wesley Street

Significance:

This deck plate girder bridge carries the former Chicago, Burlington & Quincy Railroad over the Fox River and Illinois Route 25 in Montgomery

Montgomery, Kendall County, Illinois

Owner: Illinois Railway

Status: In Use

Built 1903 and 1938

by

King Bridge Company of Cleveland, Ohio and American Bridge Company of New York

for

Chicago, Burlington & Quincy Railroad

Design:
4-78' deck plate girder, 45' steel stringer, timber pile trestle and concrete modular girder

Description:
Deck plate girder bridge over Fox River

Significance:

This through plate girder bridge carried the Elgin, Joliet & Eastern Railway over the Chicago, Rock Island & Pacific Railway mainline in Rockdale

Rockdale, Will County, Illinois

Owner: Forest Preserve District of Will County

Status: Open to Pedestrian Traffic

Built 1905

by

Unknown and Keltie Stone Company of Joliet, Illinois

for

Rockdale, Joliet & Lockport Terminal Railway

Design:
1-68', 1-45' and 1-17' through plate girders

Description:
Through plate girder bridge over CSX Corporation

Significance:

This massive through truss vertical lift bridge carries the former Chicago, Rock Island & Pacific Railway over the Des Plaines River in Joliet

Joliet, Will County, Illinois

Owner: CSX Corporation

Status: In Use

Built 1932

by

American Bridge Company of New York and Herlihy Mid-Continent Company of Chicago, Illinois

for

Chicago, Rock Island & Pacific Railway

Design:
306' subdivided polygonal Warren through truss lift span and 1-151' and 1-101' subdivided Warren through truss

Description:
Through truss lift bridge over Des Plaines River

Significance:

This massive through truss vertical lift bridge carries the former Chicago, Rock Island & Pacific Railway over the Des Plaines River in Joliet

Joliet, Will County, Illinois

Owner: CSX Corporation

Status: In Use

Built 1932

by

American Bridge Company of New York and Herlihy Mid-Continent Company of Chicago, Illinois

for

Chicago, Rock Island & Pacific Railway

Design:
306' subdivided polygonal Warren through truss lift span and 1-151' and 1-101' subdivided Warren through truss

Description:
Through truss lift bridge over Des Plaines River

Significance:

This Pratt through truss bridge carries the Katy Trail over Smith Creek west of Treloar

Treloar, Warren County, Missouri

Owner: Missouri State Parks

Status: Open to Pedestrian Traffic

Built 1907

by

King Bridge Company of Cleveland, Ohio

for

Missouri-Kansas-Texas Railway

Design:
150' Pratt through truss and timber pile trestle

Description:
Pratt through truss bridge over Smith Creek

Significance:

This massive Parker through truss bridge crosses the Kansas River at the end of Ohio Street

Kansas City, Wyandotte County, Kansas

Owner: City of Kansas City (Kansas)

Status: Abandoned

Built 1916

by

American Bridge Company of New York and Kansas City Bridge Company of Kansas City, Missouri

for

Kansas City Southern Railway

Design:
2-300' Parker through trusses and 235' spread Warren through truss

Description:
Parker through truss bridge over Kansas River

Significance:

This iconic Strauss trunnion bascule bridge carries the original Chicago & North Western Railway line over the North Branch of the Chicago River

Near North Side, Chicago, Cook County, Illinois to Near West Side, Chicago, Cook County, Illinois

Owner: Union Pacific Railroad

Status: Closed to Traffic

Built 1908

by

Toledo-Massillon Bridge Company of Toledo, Ohio and Great Lakes Dredge & Dock Company of Chicago, Illinois

for

Chicago & North Western Railway

Design:
170' Warren through truss Strauss trunnion bascule and 27' deck plate girder

Description:
Strauss trunnion bascule bridge over North Branch Chicago River

Significance:

This iconic through truss bascule bridge carries Lake Street and the CTA Pink and Green Lines over the South Branch Chicago River

Loop, Chicago, Cook County, Illinois to Near West Side, Chicago, Cook County, Illinois

Owner: City of Chicago

Status: In Use

Built 1916

by

American Bridge Company of New York; FitzSimons & Connell Dredge & Dock Company of Chicago, Illinois and Ketler-Elliott Erection Company of Chicago, Illinois

for

City of Chicago

Design:
245' Double deck Warren through truss bascule (double leaf fixed trunnion)

Description:
Double leaf Warren through truss bascule bridge over South Branch Chicago River

Significance:

This iconic through truss bascule bridge carries Lake Street and the CTA Pink and Green Lines over the South Branch Chicago River

Loop, Chicago, Cook County, Illinois to Near West Side, Chicago, Cook County, Illinois

Owner: City of Chicago

Status: In Use

Built 1916

by

American Bridge Company of New York; FitzSimons & Connell Dredge & Dock Company of Chicago, Illinois and Ketler-Elliott Erection Company of Chicago, Illinois

for

City of Chicago

Design:
245' Double deck Warren through truss bascule (double leaf fixed trunnion)

Description:
Double leaf Warren through truss bascule bridge over South Branch Chicago River

Significance:

This bridge is a rare example of a pin-connected Warren through truss

Lanesboro, Fillmore County, Minnesota

Owner: Minnesota Department of Natural Resources

Status: Open to Trail Traffic

Built 1888 and relocated here 1910

by

Keystone Bridge Company of Pittsburgh, Pennsylvania

for

Chicago, Milwaukee & St. Paul Railway

Design:
135' pin-connected Warren through truss

Description:
Warren through truss bridge over South Branch Root River

Significance:

This bobtail through truss swing span carries the BNSF mainline over the Chicago Sanitary and Ship Canal in Lemont

Lemont, Cook County, Illinois

Owner: BNSF Railway

Status: In Use

Built 1898

by

Keystone Bridge Company of Pittsburgh, Pennsylvania and MacArthur Brothers Company of Chicago, Illinois

for

Atchison, Topeka & Santa Fe Railway

Design:
398' bobtail Pratt through truss swing span

Description:
Bobtail Pratt through truss swing span over Chicago Sanitary and Ship Canal

Significance:

While this large truss lift bridge was built to serve railroad traffic on the lower deck, no railroad ever used this bridge

Yankton, Yankton County, South Dakota to South Yankton, Cedar County, Nebraska

Owner: National Park Service

Status: Open to Trail Traffic

Built 1924

by

American Bridge Company of New York and Missouri Valley Bridge & Iron Company of Leavenworth, Kansas

for

Meridian Highway Bridge Company

Design:
7 span double deck Pratt through truss

Description:
Double-decker truss lift bridge over Missouri River

Significance:

While this large truss lift bridge was built to serve railroad traffic on the lower deck, no railroad ever used this bridge

Yankton, Yankton County, South Dakota to South Yankton, Cedar County, Nebraska

Owner: National Park Service

Status: Open to Trail Traffic

Built 1924

by

American Bridge Company of New York and Missouri Valley Bridge & Iron Company of Leavenworth, Kansas

for

Meridian Highway Bridge Company

Design:
7 span double deck Pratt through truss

Description:
Double-decker truss lift bridge over Missouri River

Significance:

This small concrete arch bridge once carried the Chicago, Milwaukee, St. Paul & Pacific Railroad over an unnamed creek northeast of Grant Park

Grant Park, Kankakee County, Illinois

Owner: Private Owner

Status: Abandoned

Built 1907

by

Kinser Construction Company of Chicago, Illinois

for

Chicago Southern Railway

Design:
15' concrete arch

Description:
Concrete arch bridge over unnamed branch of Pike Creek

Significance:

This small concrete arch bridge once carried the Chicago, Milwaukee, St. Paul & Pacific Railroad over an unnamed creek southeast of Grant Park

Grant Park, Kankakee County, Illinois

Owner: Private Owner

Status: Abandoned

Built 1907

by

Kinser Construction Company of Chicago, Illinois

for

Chicago Southern Railway

Design:
15' concrete arch

Description:
Concrete arch bridge over unnamed creek

Significance:

This through plate girder bridge once carried numerous tracks of the Chicago, Rock Island & Pacific Railway/New York Central Railroad over 43rd Street

Grand Boulevard, Chicago, Cook County, Illinois to Fuller Park, Chicago, Cook County, Illinois

Owner: Regional Transportation Authority (Metra)

Status: In Use

Built 1897

by

Chicago Bridge & Iron Works of Chicago, Illinois and King Bridge Company of Cleveland, Ohio

for

Chicago, Rock Island & Pacific Railway and Lake Shore & Michigan Southern Railway

Design:
1-70' through plate girder (west tracks); 1-40' through plate girder and 2-15' steel stringer (east tracks)

Description:
Through plate girder bridge over 43rd Street

Significance:

This through plate girder bridge carries the Metra Southwest Service over 63rd Street

Englewood, Chicago, Cook County, Illinois

Owner: Regional Transportation Authority (Metra)

Status: In Use

Built 1903

by

American Bridge Company of New York

for

Chicago & Western Indiana Railroad

Design:
1-44', 1-36' through plate girder (east tracks); 70' through plate girder (west tracks)

Description:
Through plate girder bridge over 63rd Street

Significance:

This through plate girder bridge carries the Metra Southwest Service over 64th Street

Englewood, Chicago, Cook County, Illinois

Owner: Regional Transportation Authority (Metra)

Status: In Use

Built 1903

by

American Bridge Company of New York

for

Chicago & Western Indiana Railroad

Design:
60' through plate girder

Description:
Through plate girder bridge over 64th Street

Significance:

This large deck plate girder bridge carries the former New York Central Railroad over the Kankakee River on the west side of Kankakee

Kankakee, Kankakee County, Illinois

Owner: Norfolk Southern Railway

Status: In Use

Built 1903 and 1942 using spans fabricated 1896 and c. 1910

by

King Bridge Company of Cleveland, Ohio and Unknown

for

New York Central Railroad

Design:
6-69' and 2-60' deck plate girders

Description:
Deck plate girder bridge over Kankakee River

Significance:

This large Pratt through truss lift bridge carries the former Chicago, Burlington & Quincy Railroad over the Illinois River in Ottawa

Ottawa, LaSalle County, Illinois

Owner: Illinois Railway

Status: In Use

Built 1898 and reconstructed 1933

by

King Bridge Company of Cleveland, Ohio and American Bridge Company of New York

for

Chicago, Burlington & Quincy Railroad

Design:
4-176' Pratt through trusses with lift span, 73' deck plate girder and timber pile trestle

Description:
Pratt through truss lift bridge over Illinois River

Significance:

This through plate girder bridge carries the former Chicago & North Western Railway over the former Chicago, Rock Island & Pacific Railway in Owatonna

Owatonna, Steele County, Minnesota

Owner: Canadian Pacific Kansas City Limited

Status: Open to Traffic

Built 1901

by

King Bridge Company of Cleveland, Ohio and Widell Company of Mankato, Minnesota

for

Chicago & North Western Railway

Design:
45' through plate girder

Description:
Through plate girder bridge over Union Pacific Railroad

Significance:

This through and deck truss bridge is the old bridge across the Missouri River at Plattsmouth, and still serves westbound traffic

Plattsmouth, Cass County, Nebraska to Pacific Junction, Mills County, Iowa

Owner: BNSF Railway

Status: In Use; Replacement Bridge Under Construction

Built 1903

by

American Bridge Company of New York

for

Chicago, Burlington & Quincy Railroad

Design:
402' Pennsylvania through truss, 2-202', 1-200', 2-198' Pratt deck truss and deck plate girder

Description:
Through and deck truss bridge over Missouri River

Significance:

This large truss bridge carries the BNSF mainline across the Mississippi River at Quincy

Quincy, Adams County, Illinois to West Quincy, Marion County, Missouri

Owner: BNSF Railway

Status: In Use

Built 1960

by

Bethlehem Steel Company of Bethlehem, Pennsylvania and Kansas City Bridge Company of Kansas City, Missouri

for

Chicago, Burlington & Quincy Railroad

Design:
336' polygonal Warren through truss, 7-228' Warren deck trusses, 2-90' and 4-84' deck plate girders

Description:
Polygonal Warren through truss bridge over Mississippi River

Significance:

This historic Pratt through truss bridge crosses the Cedar River north of Austin

Austin, Mower County, Minnesota

Owner: Ramsey County/Minnesota Department of Natural Resources

Status: Closed to all Traffic

Built 1911 using a span fabricated 1887

by

Keystone Bridge Company of Pittsburgh, Pennsylvania

for

Chicago, Milwaukee & St. Paul Railway

Design:
2-102' Pratt through trusses

Description:
Pratt through truss bridge over Cedar River

Significance:

This large through truss bridge once carried the Chicago, Burlington & Quincy Railroad over the Rock River in Rockford

Rockford, Winnebago County, Illinois

Owner: City of Rockford

Status: Open to Pedestrian Traffic

Built 1896 and 1929 using spans fabricated 1898

by

King Bridge Company of Cleveland, Ohio

for

Chicago, Burlington & Quincy Railroad

Design:
5-150' Pratt through trusses and 2-63' deck plate girders

Description:
Pratt through truss bridge over Rock River

Significance:

This massive deck truss bridge carries the Sangmaon Valley Trail (former Chicago & North Western Railway) over the Sangamon River northwest of Springfield

Springfield, Sangamon County, Illinois

Owner: Sangamon County

Status: Open to Pedestrian Traffic

Built 1912, 1921 and c. 1975

by

King Bridge Company of Cleveland, Ohio; American Bridge Company of New York; Wisconsin Bridge & Iron Company of North Milwaukee, Wisconsin and Unknown

for

Chicago & North Western Railway

Design:
5-150' double intersection Warren deck truss, 3-85' and 1-60' deck plate girder and 40' steel stringer

Description:
Double intersection Warren deck truss bridge over Sangamon River

Significance:

This historic lattice deck truss bridge carries the Sangamon Valley Trail (former Chicago & North Western Railway) over Spring Creek on the west side of Springfield

Springfield, Sangamon County, Illinois

Owner: Sangamon County

Status: Open to Pedestrian Traffic

Built 1919 and 1921 using spans fabricated 1883, 1912 and 1921

by

Alden and Lassig Bridge & Iron Works of Chicago, Illinois; King Bridge Company of Cleveland, Ohio; Ameran Bridge Company of New York and Unknown

for

Chicago & North Western Railway

Design:
119' lattice deck truss, 2-85' and 1-60' deck plate girders and 3-11' concrete arch skeleton abutment

Description:
Historic lattice deck truss bridge over Spring Creek

Significance:

This unique Schaub variant through truss crosses the Neosho River east of Oswego

Oswego, Cherokee County, Kansas

Owner: South Kansas & Oklahoma Railroad

Status: In Use

Built 1905 and 1962

by

King Bridge Company of Cleveland, Ohio and Unknown

for

St. Louis–San Francisco Railway

Design:
153' Schaub Variant through truss, 24' deck plate girder and 2-50' steel stringers

Description:
Schaub variant through truss over Neosho River

Significance:

This Pratt through truss bridge crosses the Verdigris River on the southeast side of Neodesha

Neodesha, Wilson County, Kansas

Owner:

Status: In Use

Built 1905

by

King Bridge Company of Cleveland, Ohio

for

St. Louis–San Francisco Railway

Design:
164' Pratt through truss and 4-33' deck plate girders

Description:
Pratt through truss bridge over Verdigris River

Significance:

This iconic steel arch bridge crosses high above the St. Croix River north of Stillwater

Somerset, St. Croix County, Wisconsin to Stillwater, Washington County, Minnesota

Owner: Canadian National Railway

Status: In Use

Built 1911

by

American Bridge Company of New York and Kelly-Atkinson Construction Company of Chicago, Illinois

for

Wisconsin Central Railway

Design:
5-350' three hinged steel deck arch and deck plate girder viaduct

Description:
Massive steel arch bridge over St. Croix River

Significance:

This Warren pony truss bridge crosses the former Missouri Pacific Railroad south of Interstate 80

Omaha, Douglas County, Nebraska

Owner: Union Pacific Railroad

Status: In Use

Built 1907

by

American Bridge Company of New York and Kilpatrick Brothers of Beatrice, Nebraska

for

Union Pacific Railroad

Design:
107' Warren pony truss and 2-80' through plate girders

Description:
Warren pony truss bridge over Union Pacific Railroad (former Missouri Pacific Railroad)

Significance:

This Baltimore through truss bridge crosses an abandoned Chicago & North Western Railway line

Omaha, Douglas County, Nebraska

Owner: Union Pacific Railroad

Status: In Use

Built 1907

by

American Bridge Company of New York and Kilpatrick Brothers of Beatrice, Nebraska

for

Union Pacific Railroad

Design:
137' Baltimore through truss and deck plate girder

Description:
Baltimore through truss bridge over abandoned Chicago & North Western Railway

Significance:

This historic Pratt through truss bridge carries a trail over Stinson Creek in Fulton

Fulton, Callaway County, Missouri

Owner: City of Fulton

Status: Open to Pedestrian Traffic

Built 1902 using a span fabricated 1878

by

Kellogg Bridge Company of Buffalo, New York

for

Chicago & Alton Railway

Design:
144' Pratt through truss and trestle

Description:
Historic Pratt through truss bridge over Stinson Creek

Significance:

This attractive pony truss bridge was reused as an overpass to carry 3rd Street over the former Chicago & Alton Railroad in Delavan

Delavan, Tazewell County, Illinois

Owner: City of Delavan

Status: In Use

Built 1898 and 1907 using a span fabricated c. 1878

by

Kellogg Bridge Company of Buffalo, New York

for

Chicago & Alton Railroad

Design:
63' double intersection Warren pony truss and 17' timber stringer

Description:
Double intersection Warren pony truss bridge over Canadian National Railway

Significance:

This concrete arch bridge crosses 50th Street south of Interstate 80 in Omaha

Omaha, Douglas County, Nebraska

Owner: Union Pacific Railroad

Status: In Use

Built 1906

by

Kilpatrick Brothers of Beatrice, Nebraska and

for

Union Pacific Railroad

Design:
30' concrete arch

Description:
Concrete arch bridge over 50th Street

Significance:

This deck plate girder viaduct crosses Big Papillion Creek south of Interstate 80

Omaha, Douglas County, Nebraska

Owner: Union Pacific Railroad

Status: In Use

Built 1907

by

American Bridge Company of New York and Kilpatrick Brothers of Beatrice, Nebraska

for

Union Pacific Railroad

Design:
7 span deck plate girder viaduct

Description:
Deck plate girder viaduct over Big Papillion Creek

Significance:

This deck plate girder bridge carries the former Chicago & North Western Railway over a driveway in South Beloit

South Beloit, Winnebago County, Illinois

Owner: Union Pacific Railroad

Status: In Use

Built c. 1935 using spans fabricated 1912 and c. 1905

by

King Bridge Company of Cleveland, Ohio and American Bridge Company of New York

for

Chicago & North Western Railway

Design:
40' deck plate girder and timber pile trestle

Description:
Deck plate girder bridge over driveway

Significance:

This deck plate girder bridge carries the former Chicago & North Western Railway over County Road 69 (former US Highway 69) in Shakopee

Shakopee, Scott County, Minnesota

Owner: Union Pacific Railroad

Status: Open to Traffic

Built 1957

by

Unknown and Kraus-Anderson Construction Company of St. Paul, Minnesota

for

Chicago & North Western Railway

Design:
1-100', 1-99', 1-80' and 1-77' deck plate girders

Description:
Deck plate girder bridge over County Road 69 (Business US Highway 169)

Significance:

This large through truss bridge is the easternmost railroad bridge across the Kansas River

Kansas City, Wyandotte County, Kansas

Owner: Union Pacific Railroad

Status: In Use

Built 1903 and 1922

by

Pennsylvania Steel Company of Steelton, Pennsylvania and King Bridge Company of Cleveland, Ohio

for

Chicago Great Western Railway and Missouri Pacific Railway

Design:
246' spread Warren through truss, 3-200' Pratt through truss, 80' through plate girder and 2-16' concrete slab

Description:
Pratt through truss bridge over Kansas River

Significance:

This large through truss bridge is the easternmost railroad bridge across the Kansas River

Kansas City, Wyandotte County, Kansas

Owner: Union Pacific Railroad

Status: In Use

Built 1903 and 1922

by

Pennsylvania Steel Company of Steelton, Pennsylvania and King Bridge Company of Cleveland, Ohio

for

Chicago Great Western Railway and Missouri Pacific Railway

Design:
246' spread Warren through truss, 3-200' Pratt through truss, 80' through plate girder and 2-16' concrete slab

Description:
Pratt through truss bridge over Kansas River

Significance:

This deck plate girder viaduct crosses Little Papillion Creek and the Keystone Trail south of Interstate 80

Omaha, Douglas County, Nebraska

Owner: Union Pacific Railroad

Status: In Use

Built 1907

by

American Bridge Company of New York (presumed) and Kilpatrick Brothers of Beatrice, Nebraska

for

Union Pacific Railroad

Design:
6 span deck plate girder viaduct

Description:
Deck plate girder viaduct over Little Papillion Creek and Keystone Trail

Significance:

This quadrangular lattice through truss bridge carries the former Chicago & North Western Railway over the Mackinaw River north of Green Valley

Green Valley, Tazewell County, Illinois

Owner: Union Pacific Railroad

Status: In Use

Built 1912 and c. 1975 using a span fabricated c. 1900

by

King Bridge Company of Cleveland, Ohio and Unknown

for

Chicago & North Western Railway

Design:
130' quadrangular lattice through truss, 50' deck plate girder, 1-45' and 6-40' steel stringers

Description:
Quadrangular lattice through truss bridge over Mackinaw River

Significance:

This large girder bridge carries the former Chicago & North Western Railway over US Route 24 and Kickapoo Creek Road in Bartonville

Bartonville, Peoria County, Illinois

Owner: Union Pacific Railroad

Status: In Use

Built 1912 and 1987

by

King Bridge Company of Cleveland, Ohio, Cleary-White Construction Company of Chicago, Illinois and Unknown

for

Chicago & North Western Railway

Design:
4-35' deck plate girders, 2-58', 1-43' and 1-34' through plate girders and 16' steel stringer

Description:
Through and deck plate girder bridge over US Route 24 and Kickapoo Creek Road

Significance:

This iconic through truss bascule bridge carries Wells Street and the CTA Brown and Purple Lines over the Chicago River

Loop, Chicago, Cook County, Illinois to Near North Side, Chicago, Cook County, Illinois

Owner: City of Chicago

Status: In Use

Built 1922

by

Fort Pitt Bridge Company of Pittsburgh, Pennsylvania; FitzSimons & Connell Dredge & Dock Company of Chicago, Illinois and Ketler-Elliott Erection Company of Chicago, Illinois

for

City of Chicago

Design:
268' Double deck Warren through truss bascule (double leaf fixed trunnion)

Description:
Double leaf Warren through truss bascule bridge over Chicago River

Significance:
