Railroad Bridges in Cook County , Illinois

Cook County is located in northeast Illinois, and is the most populous county in Illinois. The seat and largest city are both Chicago.
Cities Chicago Lemont Glencoe Northbrook Evanston River Forest Arlington Heights Des Plaines Hillside Matteson Flossmoor Homewood North Riverside Lyons Melrose Park Skokie River Grove Berwyn

Random Bridges

Lake Street Bridge
Image name

Lake Street Bridge

This iconic through truss bascule bridge carries Lake Street and the CTA Pink and Green Lines over the South Branch Chicago River

Loop, Chicago, Cook County, Illinois to Near West Side, Chicago, Cook County, Illinois

Owner: City of Chicago

Status: In Use

Built 1916

by

American Bridge Company of New York; FitzSimons & Connell Dredge & Dock Company of Chicago, Illinois and Ketler-Elliott Erection Company of Chicago, Illinois

for

City of Chicago

Design:
245' Double deck Warren through truss bascule (double leaf fixed trunnion)

Description:
Double leaf Warren through truss bascule bridge over South Branch Chicago River

Significance:

Regional

BNSF Des Plaines River Bridge (Lyons)
Image name

BNSF Des Plaines River Bridge (Lyons)

(Atchison, Topeka & Santa Fe Railway Bridge #11A)

This deck plate girder bridge carries the former Santa Fe over the Des Plaines River in Lyons

Lyons, Cook County, Illinois

Owner: BNSF Railway

Status: In Use

Built 1898

by

Unknown

for

Atchison, Topeka & Santa Fe Railway

Design:
6-52' deck plate girder and 2-30' concrete slab

Description:
Deck plate girder bridge over Des Plaines River

Significance:

Local

UP Prairie Creek Bridge (Des Plaines)
Image name

UP Prairie Creek Bridge (Des Plaines)

(Chicago & North Western Railway Bridge #21)

This stone and concrete arch bridge crosses Prairie Creek on the east side of Des Plaines

Des Plaines, Cook County, Illinois

Owner: Union Pacific Railroad

Status: In Use

Built 1883 and 1929

by

Unknown and Bates & Rogers Construction Company of Chicago, Illinois

for

Chicago & North Western Railway

Design:
2-15' stone arch (north tracks) and 2-15' concrete arch (south track)

Description:
Stone and concrete arch bridge over Prairie Creek

Significance:

Local

UP Des Plaines River Bridge (Des Plaines)
Image name

UP Des Plaines River Bridge (Des Plaines)

(Chicago & North Western Railway Bridge #22)

This large through plate girder bridge crosses the Des Plaines River in downtown Des Plaines

Des Plaines, Cook County, Illinois

Owner: Union Pacific Railroad

Status: In Use

Built 1910 and 1929

by

American Bridge Company of New York

for

Chicago & North Western Railway

Design:
2-84', 1-60' and 1-50' through plate girder

Description:
Through plate girder bridge over Des Plaines River

Significance:

Local

Polly L Bridge
Image name

Polly L Bridge

(Metropolitain West Side Elevated Truss Bridge)

This abandoned Pennsylvania through truss span was left standing after much of the of the Logan Square Branch was abandoned.

Near West Side, Chicago, Cook County, Illinois

Owner: Union Pacific Railroad

Status: Abandoned, reused as signal bridge

Built 1895

by

Mt. Vernon Bridge Company of Mt. Vernon, Ohio

for

Metropolitan West Side Elevated

Design:
258' Parker through truss

Description:
Parker through truss bridge over Union Pacific Railroad

Significance:

High

UP Davis Street Bridge (Arlington Heights)
Image name

UP Davis Street Bridge (Arlington Heights)

(Chicago & North Western Railway Bridge #28)

This steel stringer bridge crosses Davis Street along US Highway 14 in Arlington Heights

Arlington Heights, Cook County, Illinois

Owner: Union Pacific Railroad

Status: In Use

Built 1929 and 1930

by

Clinton Bridge Works of Clinton, Iowa; American Bridge Company of New York; Unknown and Peppard & Burrill of Minneapolis, Minnesota

for

Chicago & North Western Railway

Design:
32' steel stringer

Description:
Steel stringer bridge over Davis Street

Significance:

Local

CN Main Street Bridge (Matteson)
Image name

CN Main Street Bridge (Matteson)

(Illinois Central Railroad Bridge #28.3)

This concrete encased beam bridge carries the Metra Electric District over Main Street in Matteson

Matteson, Cook County, Illinois

Owner: Canadian National Railway

Status: In Use

Built 1923

by

American Bridge Company of New York and Bates & Rogers Construction Company of Chicago, Illinois

for

Illinois Central Railroad

Design:
2-30' concrete encased beam

Description:
Concrete encased beam bridge over Main Street

Significance:

Local

UP Armitage Avenue Bridge (East)
Image name

UP Armitage Avenue Bridge (East)

(Chicago & North Western Railway Bridge #1297)

This through plate girder bridge carries the Union Pacific North Line over Armitage Avenue in the Logan Square neighborhood of Chicago

Logan Square, Chicago, Cook County, Illinois

Owner: Union Pacific Railroad

Status: In Use

Built 1899

by

Lassig Bridge & Iron Works of Chicago

for

Chicago & North Western Railway

Design:
43' and 2-16' through plate girders

Description:
Through plate girder bridge over Armitage Avenue

Significance:

Local

CN I-88 Bridge (Hillside)
Image name

CN I-88 Bridge (Hillside)

This through plate girder bridge crosses Interstate 88 at its eastern terminus at Interstate 290 in Hillside

Hillside, Cook County, Illinois

Owner: Canadian National Railway

Status: In Use

Built 1952 and 2000

by

Unknown

for

Illinois Central Railroad

Design:
7 span through plate girder

Description:
Through plate girder bridge over Interstate 88

Significance:

Local

UP Lathrop Avenue Bridge (River Forest)
Image name

UP Lathrop Avenue Bridge (River Forest)

(Chicago & North Western Railway Bridge #14.2)

This trough floor steel stringer bridge carries the Union Pacific West line over Lathrop Avenue in River Forest

River Forest, Cook County, Illinois

Owner: Union Pacific Railroad

Status: In Use

Built 1912

by

American Bridge Company of New York

for

Chicago & North Western Railway

Design:
2-24' and 2-10' trough floor steel stringer

Description:
Trough floor steel stringer bridge over Lathrop Avenue

Significance:

Local
